CMOS Color Microscope Digital Cameras
STC2B Series USB2.0 digital cameras are mainly designed for microscopes to capture microscope images, videos and display real-time live video on your PC screen. They come with a high-resolution digital camera, built-in IR filter and user-friendly software. Adapters for all sizes of microscopes are optional. The cameras can provide high quality image and are widely used in academic and medical field for high precision and resolution image capturing and processing.
|
Model |
STC2B-130C |
STC2B-320C |
STC2B-500C |
STC2B-1000C |
|
Image Sensor |
1/2.5” CMOS Sensor, Micron MT9P031 |
1/2” CMOS Sensor, Micron MT9T001 |
1/2.5” CMOS Sensor, Micron MT9P031 |
1/2.3” CMOS Sensor, Micron MT9J001 |
|
Effective Pixels |
1.3MP |
3.2MP |
5.0MP |
10.0MP |
|
Resolution |
1272×952 |
2048×1536 |
2592×1944 |
3856×2764 |
|
Pixel Size |
2.2μm×2.2μm |
3.2μm×3.2μm |
2.2μm×2.2μm |
1.67μm×1.67μm |
|
Frame Rate |
16fps@1272×952 46fps@632×472 |
12fps@2040×1528 33fps@1016×760 46fps@632×472 |
6fps@2584×1936 15fps@1272×952 23fps@632×472 |
3fps@3656×2740 7fps@1824×1362 33fps@908×672 |
|
Sensitivity |
1.4 V/lux-S(550nm) |
1.0 V/lux-S(550nm) |
1.4 V/lux-S(550nm) |
0.44 V/lux-S(550nm) |
|
Exposure Time |
0.001-0.2 sec |
0.001-0.5 sec |
0.001-0.5 sec |
0.001-0.5 sec |
|
Dynamic Range |
60dB |
54dB |
60dB |
56dB |
|
SNR |
40.5dB |
43dB |
40.5dB |
43dB |
|
Color Depth |
24bit |
|||
|
A/D |
8-bit |
|||
|
Exposure Control |
Auto/Manual |
|||
|
White Balance |
Auto/Manual |
|||
|
Scan Mode |
Progressive Scan |
|||
|
Shutter Type |
Electronic rolling shutter |
|||
|
Filter |
RGB filter |
|||
|
Lens Interface |
C/CS |
|||
|
Data Output |
USB2.0, 480Mb/s |
|||
|
Power Supply |
USB2.0, 500mA |
|||
|
Working Temperature |
0°C ~ 60°C |
|||
|
Storage Temperature |
-20°C ~ 70°C |
|||
|
Working Humidity |
45%~ 85% |
|||
|
Operating System |
Windows 2000/XP/ Vista/Win7/Win8/Win 10/Mac |
|||
|
Size and Weight |
69mm×87mm×44mm, 220g |
|||
